1. Size available DN50-DN300

2. Proven spiral wound, crimped ribbon, flame element.

3. Low pressure drop with multiple element size available for each flange size.

4. Easy cleaning, bi-directional flame arrester.

5. Suitable for standing tanks containing first catagory oil whose flash point is lower than 28 centigrade or second catagory oil whose flash point lower than 60 centigrade, such as petroleum, tolueue, kerosene, coal oil and base oil.

6. can be used with pressure/vacuum relief valve, vertical or horizontal installation.

7. Steam jacket, blowing hole, test hole absorber are options to clients.

8. Flanges are accordance with ANSI B16.5 or EN1092 or JIS.

9. Available materials: Aluminium, carbon steel, stainless steel, special materials on application.
