Description

◎ install valves:2-way,3-wayball valve and brtterfly valve
◎ Rated voltage: DC12V,DC24V,AC24V/110V/230VAC/DC95V-265V,AC/DC24V
◎ Running time: about 3-5S
◎ Timer mode: pulse mode , time mode
◎ Control signal: 4-20mA,0-20mA,0-10V,0-5V,1-5V,2-10V
◎ Position feedback: 4-20mA
◎ Position accuracy: ±1%
◎ Timer mode: pulse mode , time mode
◎ Loop mode : loop by days , loop by weeks
◎ Communication Mode: RF433/868/915MHZ,FSK,LORA,RF Ocean (single control)
◎ Communication protocol: Compatible Modbus
◎ Wireless Module: SX1278/SX1276/A7108
◎ Communication distance: The max is 3Km
◎ Control feedback mode:RS485(Modbus),CANBus 2.0B(customized),Mbus(customized),YW44 ( achieve the level control
   by directly connected to the level sensor), KT32J,B3S,B3P,B3R,B3SR,BD3S,BD3J,B3J,B33J,B43J(synchronous)
◎ Alarm output: A(Relay contact feedback)
◎ Be achievable: 2 way mode/3 way mode
◎ High performance brushless motor,overload protection with motor self-clock unit of internal
◎ It can be used up to 20,000 times
◎ Two or more actuators can be used in parallel
※ For AC series,it is forbidden to use two or more actuators in parallel
※RS485 could parallel 32/64/256 actuators in max,while CANBus parallels 110 actuators

Qingdao I-Flow Co., Ltd

Qingdao I-Flow Co., Ltd


Specification

Simple on/off actuator selection guide- Standard Series

Model
Torque
Voltage
Wiring
Feedback
Time
Speed
regulation
Rotation
angle
Enclosure
Manual
override
Position
indicator
Housing
materia
Output
shaft
TCR-06N
60Nm
DC24V
B3/BD3
S Type
P Type
R Type
10s
None
90°/180°
≤330°
IP67
or
F Type
Hexagon
spanner
Mechanical
indicator
ABS
Female
octagon
AC24V
AC110V
AC230V

15S
TCR-11N
110Nm
DC24V
B3/BD3
S Type
P Type
R Type
15s
None
90°/180°
≤330°
IP67
or
F Type
Hexagon
spanner
Mechanical
indicato
ABS
octagon
AC24V
10s
AC110V
AC230V
15s
